Box-style roll-offs from 10 to 50 yards for cable and hooklift systems, built in five duty classes from light cleanouts to high-impact service. Cut, formed and welded in Waterbury, CT, by a team with a combined 50+ years in the waste industry.
For light construction and cleanouts. Main rails 3/16 in.; floor 10 ga; crossmembers 3 in. channel, 24 in. on center; bulkhead 10 ga; sides 12 ga; side posts 3 x 9 in., 12 ga, 4-way bends; top rail 3 x 4 in., 11 ga.
For general duty service. Main rails 3/16 in.; floor 7 ga; crossmembers 3 in. channel, 16 in. on center; bulkhead 10 ga; sides 12 ga; side posts 3 x 9 in., 12 ga, 4-way bends; top rail 3 x 4 in., 11 ga.
For demanding daily service. Main rails 1/4 in.; floor 1/4 in.; crossmembers 13 in. channel, 12 in. on center; bulkhead 10 ga; sides 10 ga; side posts 3 x 9 in., 10 ga, 4-way bends; top rail 3 x 4 x 1/4 in.
For severe service. Main rails 1/4 in.; floor 1/4 in.; crossmembers 3 in. channel, 12 in. on center; bulkhead 7 ga; sides 7 ga; side posts 3 x 9 in., 7 ga, 2-way bends; top rail 3 x 4 x 1/4 in.
For high-impact service. Main rails 1/4 in.; floor 1/4 in.; crossmembers 3 in. channel, 12 in. on center; heavy-duty bulkhead, sides and side posts; top rail 3 x 4 x 1/4 in.
ANSI vertical-lift latches with guide track; four HD 4 x 6 in. greasable rollers; greasable hinges with Zerk fittings. Sizes: 10, 12, 15, 20, 25, 30, 35, 40 and 50 yard, plus a 12 yard on a 12 ft platform. Full dimensions are on the spec sheet.
Not sure which size, duty class or door style fits the route? Call the shop at 203-456-8811, Monday to Friday, 7 am to 4 pm.
