Stationary Compactors
Stationary compactors with 2, 3, 4 and 5 yard heads, with abrasion-resistant floors, a cross-cylinder design and TEFC tri-voltage motors. Built in Waterbury, CT, by a team with a combined 50+ years in the waste industry.
Specifications
Head Sizes
Construction and Hydraulics
Construction and Hydraulics
Dimensions A, B, C, D, E and F per the spec sheet drawing. 2 yard: 48, 120, 58, 42, 58, 64 in. 3 yard: 48, 170-3/4, 58, 42, 58, 64 in. 4 yard: 53, 170-3/4, 58, 47, 58, 64 in. 5 yard: 53, 239, 58, 47, 58, 96 in. Cylinder bore 6-1/2 in. on every head.
Construction and Hydraulics
Construction and Hydraulics
Construction and Hydraulics
Abrasion-resistant steel floors and ram floors; cross-cylinder design with extra heavy-duty cylinders and 5 in. penetration; TEFC tri-voltage motors; operator controls with 15 ft Sealite; built to ANSI standards.
Typical Applications
Typical Applications
Typical Applications
Supermarkets, fast food and restaurants, hotels, casinos, food handling companies and hospitals.
Options
Typical Applications
Typical Applications
Single-phase voltage, bio hydraulic oil, guide rails, ozone odor control system, doghouse with door on one or both sides, hopper setups, thru-wall chute (rear or side), hatchway setups and other custom options. Full dimensions are on the spec sheet.
Recent Stationary Compactor Builds
Request a Quote
Talk to a Builder
Not sure which size, duty class or door style fits the route? Call the shop at 203-456-8811, Monday to Friday, 7 am to 4 pm.
